Solução De Storage Ibm Xiv Gen3 360tb Sas Enterprise Edition Type 2810-114 (Usado)

Descrição

IBM System Storage XIV Storage System Modelo R3 2810-114 (2810-114)

SOLUÇÃO DE STORAGE IBM COM CONTROLADORA SERVER RAID INTERNA COM SOFTWARE DE GESTÃO:

INTERFACE: FIBER CHANNEL 8GB/S

O CONJUNTO CONTEMPLE 180 DISCOS DE 2TB SAS 7.2K IBM COM TOTAL DE 360 TERABYTES BRUTO DISTRIBUIDOS EM


STORAGE IBM COM CONTROLADORA INTERNA PARA RAID 0, RAID 1, RAID 10, RAID 3, RAID 5, RAID 6

EQUIPAMENTO REVISADO PRONTO PARA USO, ENVIAMOS TODA DOCUMENTAÇÃO PARA UTILIZAÇÃO E CONFIGURAÇÃO, FORNECEMOS SUPORTE TÉCNICO.


O IBM 2812 XIV Storage System Gen3 Modelo 114 para os tipos de máquina 2810 e 2812 é um sistema de disco aberto inovador e sofisticado projetado para ajudar a reduzir custos, simplificar o gerenciamento e acelerar o acesso a dados importantes. O IBM XIV Storage System Modelo 114 para os tipos de máquina 2810 e 2812 agora oferece unidades de disco rígido Serial-Attached SCSI (SAS) de 3 Terabytes (TB) preenchidas na interface XIV e nos módulos de dados.
O IBM XIV Storage System Gen3 com software release 11.1 agora inclui suporte para IBM XIV SSD Caching opcional. Esse novo recurso foi projetado para fornecer um aumento de desempenho para sistemas Gen3 com mais capacidade de cache do que a RAM DIMM existente e a capacidade de atender até 3x o desempenho para cargas de trabalho OLTP. Com cache SSD, o Gen3 com software versão 11.1 fortalece ainda mais sua capacidade de fornecer alto desempenho consistente e funcionalidade corporativa, juntamente com baixo custo total de propriedade (TCO) e facilidade de uso. Os aprimoramentos nesta versão destinam-se a permitir:
Obtenha taxa de acerto de leitura aleatória e desempenho de IOPS
Beneficie-se da combinação de tecnologia SSD e implementação de cache XIV exclusiva

DADOS COMPLETOS DA IBM

Abstract
The IBM 2810 XIV Storage System Gen3 Model 114 for machine types 2810 and 2812 is an innovative, high-end, open disk system designed to help reduce costs, simplify management and speed access to important data. IBM XIV Storage System Model 114 for machine types 2810 and 2812 is now offering the 3 Terabyte (TB) Serial-Attached SCSI (SAS) hard disk drives populated in the XIV interface and data modules.

IBM XIV Storage System Gen3 with software release 11.1 now includes support for optional IBM XIV SSD Caching. This new feature is designed to provide a performance boost for Gen3 systems with more cache capacity than existing DIMM RAM and the ability to serve up to 3x the performance for OLTP workloads. With SSD caching, Gen3 with software release 11.1 further strengthens its ability to provide consistent high performance and enterprise functionality, along with low total cost of ownership (TCO) and ease of use. The enhancements in this release is intended to enable:

Obtain random read hit ratio and IOPS performance
Benefit from the combination of SSD technology and unique XIV caching implementation
Model abstract 2810-114
The IBM 2812 XIV Storage System Gen3 Model 114 together with IBM 2810 XIV Storage System Gen3 Model 114 enable a flexible warranty choice for XIV Gen3 storage. The 2812 Model 114 supports a 3-year warranty to complement the 1-year warranty offered by the functionally equivalent, 2810 Model 114.

Highlights
IBM XIV Storage Systems Gen3 is designed to provide a higher-performing option in enterprise-class storage from the IBM XIV Storage System series. XIV Gen3 model 114 offers up to four times the performance of previous generation systems and includes:

A virtualized grid-based array of storage devices
Up to 180 2 TB Serial Attached SCSI (SAS) hard disk drives
Up to 161 TB of useable capacity in a single frame
Up to 24 ports of 8Gb Fibre Channel host connectivity
Up to 22 ports of 1Gb iSCSI host connectivity
Up to 360 GB of cache
High-performance InfiniBand interconnectivity
Multi-core processors
Advanced software functions:
Synchronous and asynchronous remote mirroring
Thin provisioning
Data migration
Quality of Service controls
LDAP authentication support
VMware VAAI support
Differential, writeable snapshot technology
One and three-year warranty models
SSD caching increases the effective amount of read cache available to the system, with an emphasis on a read-cache for random I/O.
Designated SSD drives on each module is intended to be up to 0.4 TB, providing increased performance with higher cache hits compared to disk drives.
Description
The IBM XIV Storage System Gen3 represents the third generation of the IBM XIV series of storage systems and offers:

Up to 180 2 TB Serial Attached SCSI (SAS) hard disk drives
Up to 161 TB of useable capacity in a single frame
Up to 24 ports of 8Gb Fibre Channel host connectivity
Up to 22 ports of 1Gb iSCSI host connectivity
Up to 360 GB of cache
High-performance InfiniBand interconnectivity
Multi-core processors
Three uninterruptible power supplies
IBM XIV Storage System Gen3 will be upgradeable to an SSD Caching option which is planned for the first half of 2012. The SSD caching option is being designed to provide up to 6 TB of fast read cache to support and up to a 90% reduction in I/O latency for random read workloads.

IBM 2812 XIV Storage System Gen3 Model 114 together with IBM 2810 XIV Storage System Gen3 Model 114 enable a flexible warranty choice for XIV Gen3 storage. 2812 Model 114 supports a 3-year warranty to complement the 1-year warranty offered by the functionally equivalent, 2810 Model 114.

IBM XIV Storage System Gen3 models are part of a series of IBM XIV Storage Systems.

The IBM XIV Storage System series is an innovative, high-end, open disk system series designed to support business requirements for a highly available information infrastructure. The XIV architecture is a grid of standard Intel and Linux components connected in any-to-any topology. This architecture is designed to support enterprise-class reliability, performance, and scalability.

IBM XIV Storage System Gen3 carries on the XIV tradition of providing consistent, high performance, and high reliability with a low total cost of ownership. Several design factors contribute to this achievement:

Self-tuning and self-healing: XIV's unique fully virtualized architecture supports high system performance without manual tuning. The system can self-optimize automatically upon changes in the hardware configuration, such as the addition of modules or replacement of modules upon failure.
Ease of management: Ease of management that goes below the surface, with a virtualized architecture, highly intuitive GUI, and clever implementation of role-based management all add up to create a streamlined user experience, with less administration.
High performance: A high-speed InfiniBand internal interconnect, load balancing, use of all system resources, innovative caching, and massive CPU power combine to support high performance.
Enhanced Connectivity: The IBM XIV Gen3 offers improved host connectivity with up to twenty-four 8Gbps Fibre Channel ports and up to twenty-two 1Gbps iSCSI host connectivity ports.
Reliability: High reliability and availability through hardware redundancy, rapid rebuild times, automatic self-healing, and preemptive, proactive support services.
Improved capacity usage: Efficient capacity utilization functionality, including space-efficient snapshots and advanced thin provisioning, helps support savings in capacity and cost, and less administration requirements.
High-Density Storage: Enterprise-class, high density SAS disk drives create increased physical space efficiencies. Using 2 TB drives. XIV Gen3 provides 161 TB useable capacity in a single rack. The ability to store so much data in one system using fewer, large capacity drives, as well as the use of multi-core processors, can help to reduce power and cooling expenses for a more energy-efficient solution.
Innovative Caching: Up to 360 GB of total system cache with flexible and powerful cache implementation allows the XIV system to leverage large slots for reads while enabling it to manage a smaller slot size for improved cache management and better performance.
IBM XIV Storage System Gen3 will be upgradeable to an SSD Caching option which is planned for the first half of 2012. The SSD caching option is being designed to provide up to 6 TB of fast read cache to support and up to a 90% reduction in I/O latency for random read workloads.

Flexible Warranty: Configurations are available in both one-and three-year warranty options.
Capacity on Demand Configurations: CoD configurations are available to provide a method to quickly provision new physical storage and can be ordered at any of the valid partially populated capacities. Up to three CoD modules can be over-provisioned. Contact your sales representative for further details on CoD conditions.

Garantia do vendedor: 1 anos
